مادربرد تجاری Micro-ATX H310 با امنیت، قابلیت اطمینان و مدیریت بیشتر فناوری BIOS خودبازیابی انحصاری ایسوس برای بازیابی خودکار بایوس سیستم از یک نسخه پشتیبان تایید شده هدر اشکال زدایی ASUS LPC برای عیب یابی کارآمدتر گزارش رویداد برای گرفتن و مدیریت اطلاعات دقیق سیستم پوشش نوآورانه مقاوم در برابر رطوبت برای محافظت از مادربرد در برابر محیط های خشن کیت BIOS تجاری برای سفارشی سازی سریعتر و کارآمدتر
https://www.itkala.net
-
نوع سوکت پردازنده
Intel LGA ۱۱۵۱
-
پردازنده های پشتیبانی شده
9th/8th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors
Supports Intel 14 nm CPU
Supports Intel Turbo Boost Technology 2.0
* The Intel Turbo Boost Technology 2.0 support depends on the CPU types
-
حداکثر حافظه پشتیبانی
32 گیگابایت
-
توضیحات حافظه
2xDIMM, Max. 32GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
Supports Intel® Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
The maximum memory frequency supported varies by processor.
** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.
-
اسلات PCI Express x16
دو عدد
-
سایر توضیحات کارت گرافیک
Integrated Graphics Processor- Intel® HD Graphics support
Multi-VGA output support : DVI-D/RGB ports
- Supports DVI-D with max. resolution 1920 x 1200 60 Hz
- Supports RGB with max. resolution 1920 x 1200 60 Hz
Maximum shared memory of 1024 MB (for iGPU exclusively)
Supports Intel® InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider
Supports up to 2 displays simultaneously
-
اسلات PCI Express x1
2 عدد
-
توضیحات تکمیلی هدرها
1x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
1x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
1x M.2 Socket 3 with M key, type 2260/2280 storage devices support (SATA & PCIE x2 mode)
1x LPT header
2x COM port(s) connector(s)
4x SATA 6Gb/s connector(s)
1x CPU Fan connector(s) (1 x 4 -pin)
1x Chassis Fan connector(s) (1 x 4 -pin)
1x 24-pin EATX Power connector(s)
1x 4-pin ATX 12V Power connector(s)
1x Front panel audio connector(s) (AAFP)
1x System panel(s)
1x Chassis Intrusion connector(s)
1x Clear CMOS jumper(s)
1x 14-1 pin TPM connector
1x LPC Debug header
1x Speaker connector
-
توضیح تکمیلی پورتهای USB
Intel® H310 Chipset :
2x USB 3.1 Gen 1 port(s) (2 at mid-board)
Intel® H310 Chipset :
6x USB 2.0 port(s) (4 at back panel, , Type-A, 2 at mid-board)
-
ویژگیهای خاص
Bespoke Motherboard Design & Business Focused Features :
- ASUS Self Recovering BIOS: Automatically recover BIOS update once crash happen
- ASUS Event Log: Record activities of system and provides information in BIOS
- ASUS Commercial BIOS kit: Speed up BIOS update solutionby partial BIOS design
- Anti-Moisture: Against moisture and corrosion — prolonging the life of your motherboard
- 24/7 Reliability: Tested under temperature up to 45°C and humidity up to 80% to ensure handle diverse environment
Easy Assembly Design:
- Fixed-position&Color-coded Connectors: Enable easy identification and cable-matching, speeding up the production line
- Box Headers: USB headers are box style, enabling fast connector installation and preventing pin damage
Digi+VRM
-
مشخصات تکمیلی
سایر توضیحات بایوس:
128Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS smart recovering BIOS, ASUS Event log, ASUS Commercial Kit
-
توضیح تکمیلی ذخیرهسازیStorage
Intel® H310 Chipset :
1x M.2 Socket 3, with M Key, type 2260/2280 storage devices support (both SATA & PCIE mode)
4x SATA 6Gb/s port(s)
